CARBON STEEL PIPE AND TUBES

CARBON STEEL PIPE AND TUBE: API 5L, API 5CT, 5DP, ASTM A106, A106, A53, A210, A213, A333, A335,

CARBON STEEL PIPE AND TUBES: API 5L, API 5CT, 5DP, ASTM A106, A106,ASTM A53, A210, A213, A333, A335,


  • ASTM A106, A53, A179, A192, A252, A333


    Carbon Steel Pipe and Tubes ASTM A106 Gr A/B, A53 Gr,A/B. ASTM A106, ASTM A53, ASTM A179, ASTM A192, ASTMA252, ASTM A333. Carbon Steel Pipes are widely use in many industries like petrochemical, marine, ships, boiler, heat exchanger, bridges, railways, buildings, and also in many machinery plants. Usually made out of carbon content, suitable for structural building, conveying fluids, oil, and gas,slurry, and other liquids.n

  • ASTM A53


    Carbon steel pipe ASTM A53 IS widely use in generating plants. water, air, natural gas transmission, gas pipelines, mechanical and pressure applications. Steel materials are used to create seamless pipe and welded pipe must be produced via open hearth, electric furnace, basic oxygen, or any combination of these processes. All weld seams in electric-resistance welded A53 Grade B pipe must be heat treated after welding to a minimum of 1,000°F (540°C) to eliminate low un-tempered martensite.

  • ASTM A335 P9,P11,T22,T91


    Carbon steel pipe ASTM A53 IS widely use in generating plants. water, air, natural gas transmission, gas pipelines, mechanical and pressure applications. Steel materials used to create seamless pipe and welded pipe must be produced via open hearth, electric furnace, basic oxygen, or any combination of these processes. All weld seams in electric-resistance welded A53 Grade B pipe must be heat treated after welding to a minimum of 1,000°F (540°C) to eliminate low untempered martensite.

  • ASTM A335, A333,


    ASTM A333 Standard Specification for Seamless and Welded Steel Pipe for Low Temperature Service section 4.2.1.1; section 4.2.1.2 or section 4.2.1.3nQuenched and Tempered per A 333/A 333M – 05 section 4.2.2.1nDouble Normalized and Tempered per A 333/A 333M – 05 section 4.2.2.2

  • ASTM A179, A192, A210, A213


    Heat exchanger tubes, Condenser, Boiler Tube, Super heater tubes: ASTM A179, ASTM A210, ASTM A192, ASTM A213

  • API 5L-PSL1, API 5L-PSL2,


    API SPEC 5L are mostly used for line pipe, crack propagation, sewage, high resistance application, for conveying water, gas, and petroleum industries. Grades X42, X46, X52, X56, X60, X65, X70, and X80. nAPI 5L Welded — Grades B (X42, X52, X60, X65 and X70) PSL 1, PSL 2





CARBON STEEL PIPES AND SEAMLESS TUBES


CARBON STEEL PIPES
  • ASTM A106 GR, A,B,C.
  • ASTM A53 GR. B
  • ASTM A333 GR, 6
  • ASTM A135
  • ASTM A139
  • ASTM A179 TUBE
  • ASTM A210 TUBE
  • ASTM A333
  • ASTM A334
  • ASTM A500
  • ASTM A501
  • ASTM A512 TUBE
  • ASTM A513 TUBE
  • ASTM A517 TUBE
  • ASTM A519 TUBE
  • ASTM A671
  • ASTM A672
  • ASTM A252
API 5L PIPES
  • API 5L GR, B PSL 1
  • API 5L GR, B PSL 2
  • API 5L X42 PSL 1
  • API 5L X42 PSL 2
  • API 5L X46 PSL 1
  • API 5L X46 PSL 2
  • API 5L X52 PSL 1
  • API 5L X52 PSL 2
  • API 5L X56 PSL 1
  • API 5L X56 PSL 2
  • API 5L X60 PSL 1
  • API 5L X60 PSL 2
  • API 5L X65 PSL 1
  • API 5L 652 PSL 2
API 5L PIPES
  • API 5L X70 PSL 1
  • API 5L X70 PSL 2
  • API 5L X80 PSL 1
  • API 5L X80 PSL 2
  • API 5L SMLS
  • API 5L WELDED
  • API 5L IBR
  • API 5L ERW
  • API 5L LSAW
  • API 5L SSAW
  • API 5L EFW

API API 5L

 Conveying gas, water, and oil in the natural gas and oil industries, and covers seamless and welded steel line pipe.

API 5CT

Oil well casing and tubing

API 5DP

Drill Pipe for well drilling

ASTM

ASTM A53

Steel, Black and Hot-Dipped, Zinc-Coated, Welded & Seamless

ASTM A106

Seamless Carbon Steel Pipe use for  High-Temperature Service

ASTM A105

Carbon steel forgings for piping applications

ASTM A179

Seamless Cold-Drawn Low-Carbon Steel use for Boiler, Condenser Tubes, and Heat-Exchanger

ASTM A192

Seamless Carbon Steel Boiler Tubes used for High-Pressure Service

ASTM A210

Seamless medium carbon steel boiler and super-heater tubes

ASTM A213

Seamless Ferritic, Austenitic Alloy-Steel Boiler, Heat-Exchanger Tubes, and Super-heater

ASTM A234

Piping fittings of wrought carbon steel and alloy steel for moderate and high temperature service.

ASTM A252

Welded and Seamless Steel Pipe and Piling

ASTM A333

Seamless and Welded Steel Pipe for Low-Temperature Service. Also use for other Applications with Required Notch Toughness

ASTM A519

Seamless carbon steel and Alloy steel mechanical tubing

ASTM A672

Electric-Fusion-Welded Steel Pipe for High-Pressure Service at Moderate Temperatures

ASTM A335

Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service

DIN

DIN 17175

seamless steel pipe use for boiler installations, high-pressure pipelines and tank construction and special machinery for both high temperature and high-pressure devices.

DIN 1629

This denotes Seamless Circular Tubes of Non Alloys Steels for Special Quality Requirements.

DIN 2391

Cold Drawn High Precision Seamless Tube

DIN 2458

Welded Steel Pipes in Unalloyed and Low Alloy Steels for Supply Purposes

EN

EN 10210

Hot finished structural hollow of non-alloy steel

EN10216

Seamless steel tube for pressure

JIS

JIS G3454

Seamless carbon steel pipes for pressure service

JIS G3456

Seamless carbon steel pipe for high temperature

JIS G3461

Seamless carbon steel pipe for boiler and heat exchanger

BS

BS 3799

Steel pipe fittings, screwed and socket welded for the petroleum industry.

BS 3059

Steel boiler and super-heater tubes

BS13872

Screwed and socket steel tube and tubular

AS

AS1163

Structural steel hollow sections

AS 1074

Steel tubes and tubular for ordinary service

High Temperature Seamless Pipe

ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B

 Heat Exchanger Seamless Tube

ASTM A179

Low Temperature Seamless Pipe

ASTM A333 Gr. 3/6

 Low Temperature Seamless Tube

ASTM A334 Gr. 6

High Yield Seamless Pipe

API 5L Gr. X42 X46 X52 X56 X60 X65 X70 X80 PSL-1/PSL-2

High Yield Seamless Pipe

ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485

 Atmospheric & Low Temp EFW Pipes

ASTM A671 Gr. CC60/CC65/CC70

 High Pressure & Moderate Temp EFW Pipes

ASTM A672 Gr. B60 B65 B70 C55 C60 C65 C70

 High Yield ERW/SAW Pipe

API 5L Gr. X42 X46 X52 X56 X60 X65 X70 X80 PSL-1 PSL-2

 High Yield ERW/SAW Pipe

ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485

Chemical Composition & Mechanical Property

All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.

PSL 1
GRADE Chemical Composition Mechanical Property
C (Max) Mn (Max) P (Max) S (Max) TENSILE ( Min ) YIELD ( Min )
Psi X 1000 Mpa Psi X 1000 Mpa
A25 CL   I 0.21 0.60 0.030 0.030 45 310 25 172
CL  II 0.21 0.60 0.030 0.030
A 0.22 0.90 0.030 0.030 48 331 30 207
B 0.26 1.20 0.030 0.030 60 414 35 241
X42 0.26 1.30 0.030 0.030 60 414 42 290
X46 0.26 1.40 0.030 0.030 63 434 46 317
X52 0.26 1.40 0.030 0.030 66 455 52 359
X56 0.26 1.40 0.030 0.030 71 490 56 386
X60 0.26 1.40 0.030 0.030 75 517 60 414
X65 0.26 1.45 0.030 0.030 77 531 65 448
X70 0.26 1.65 0.030 0.030 82 565 70 483
PSL 2
GRADE Chemical Composition Mechanical Property
C
(Max)
Mn
(Max)
P
(Max)
S
(Max)
Tensile Yield C. E.      IMPACT ENERGY
Psi x 1000 Mpa Psi x 1000 Mpa PCM IIW J FT/LB
B 0.22 1.20 0.025 0.015 60 - 110 414 - 758 35 - 65 241 - 448 0.25 0.43 T/L 27/41 T/L 20/30
X42 0.22 1.30 0.025 0.015 60 - 110 414 - 758 42 - 72 290 - 496 0.25 0.43 T/L 27/41 T/L 20/30
X46 0.22 1.40 0.025 0.015 63 - 110 434 - 758 46 - 76 317 - 524 0.25 0.43 T/L 27/41 T/L 20/30
X52 0.22 1.40 0.025 0.015 66 - 110 455 - 758 52 - 77 359 - 531 0.25 0.43 T/L 27/41 T/L 20/30
X56 0.22 1.40 0.025 0.015 71 - 110 490 - 758 56 - 79 386 - 544 0.25 0.43 T/L 27/41 T/L 20/30
X60 0.22 1.40 0.025 0.015 75 - 110 517 - 758 60 - 82 414 - 565 0.25 0.43 T/L 27/41 T/L 20/30
X65 0.22 1.45 0.025 0.015 77 - 110 531 - 758 65 - 82 448 - 565 0.25 0.43 T/L 27/41 T/L 20/30
X70 0.22 1.65 0.025 0.015 82 - 110 565 - 758 70 - 82 483 - 565 0.25 0.43 T/L 27/41 T/L 20/30
X80 0.22 1.90 0.025 0.015 90 - 120 621 - 827 80 - 102 552 - 705 0.25 0.43 T/L 27/41 T/L 20/30
